Lab Water System
ZYUM ultra pure water system

ZYUM series ultrapure water machines adopts distilled water, pure water or deionized water as feed water with PLC  control and LCD disply, quickly purifying feed water and producing standard grade I ultrapure water. It suits for those people who use bottle water as feed water.Flow Schematic


Specifications

ModelZYUM-I-90LZYUM-II-90LZYUM-III-90LZYUM-IV-90L
Output(25°C)*90 liters/hour
Flow rateUp to 2.0 liters/minute(with pressure tank)
Feed water requirementsRO water (Conductivity<20μs/cm)
Ultrapure water quality
Resistivity(25°C)18.2MΩ.cm18.2MΩ.cm18.2MΩ.cm18.2MΩ.cm
Particle(>0.1μm)<1/ml<1/ml<1/ml<1/ml
Bacteria< 1cfu/ml< 1cfu/ml< 1cfu/ml< 1cfu/ml
Heavy metal ion<0.1ppb<0.1ppb<0.1ppb<0.1ppb
Endotoxin(Pyrogens)****//<0.001EU/ml<0.001EU/ml
TOC Level***< 10 ppb< 3 ppb< 3ppb< 3ppb
RNases//<0.01ng /ml<0.01ng /ml
DNases//<4pg /ul<4pg /ul
Dimension and weightLength*Width*Height: 530*400*590mm, 40Kg
Electrical requirementsAC210-240V, 50/60Hz
Terminal disinfection filter yesyesyesyes
UV lampN/Ayesyesyes
UFN/AN/Ayesyes
Standard configurationMain body (Including 1 set of cartridge)+40 liters pressure tank
Water application

○ICP-MS(Inductively Coupled Plasma Mass Spectrometry), Electrochemistry, Electrophoresis;

○Molecular biology technique, Ultratrace analysis, IC(Ion Chromatography), Molecular biology;

○GFAAS(Graphite Furnace Atomic Absorption Spectrophotometry), HPLC, Plant tissue culture;

○ICP-AES(Inductively Coupled Plasma Atomic Emission Spectrometry), Qualitative analyses;

○Mammalian&bacterial cell culture, Qualitative analysis, Ultra trace analysis, Weatern blotting;

○Buffer conventional physical&chemical detection, Biochemical analysis of chemical reagents;

○Mammalian and bacterial cell culture, Northern and Southern blotting, Qualitative analysis;

PCR(Polymerase chain reaction) Plant tissue culture, AES(Atomic Emission Spectrometry);

○AAS(Atomic Absorption Spectrophotometry)  Electrophysiology, Buffer and media preparation.

Can be selected flow rate ( L/H)90L/H

Features and Advantages

○  It is the most representative products in Chinese lab water market.

○  2 way online water quality sensor,RO water, deionized water, or ultrapure water respectively.

○  Cartridges replacing alarm function, based on time and water quality, show cartridges´ used and residual life.

○  Multiple alarm function: no feed water, full water, water quality´s standard exceeding, and cartridge life ending.

○  Auto self-flushing of RO membrane function, extend RO membrane´s life.

○  System sanitizing procedure, achieve the disinfection of ultrapure water´s tube and valve.

○  Water dispensing function- timing and quality (time range: 1-99min, water quality range: 0.1-18.2MΩ.cm).

○  External water tanks is optional to meet different need and assure ample water-supply.

○  Whole plastic shell with high-strength, avoid rusting and keep clean, to meet GLP standard.

○  2 door and easy-to-replacing cartridge design, convenient to maintain system and replace cartridges.

○  Auto running data storing function with built-in SD card, and data can be exported through the USB interface.

○  Tube and adapter with NSF authorization and top quality, reduce TOC level and assure ultrapure water´s quality.

○  Optimized pretreatment (including PP fiber,  active carbon cartridge), effectively protect RO membrane.

○  Top polishing resin, ensure ultrapure water´s quality up to 18.2 MΩ.cm, with the lowest TOC level.

○  Terminal disinfection filter, assure that terminal pure water is absolutely axenic.

○  Double wavelength (185&254nm) ultraviolet lamp module, restrain bacteria´s increase and reduce TOC.

○  MWCO 5000D ultrafiltration module, effectively eliminate endotoxin, and suitable for precise cell cultivating and IVF.
